Your Trusted Partner in Medical Supplies

Monitor Your Health From a drop of blood from your fingertip

SimplexTAS™

A new generation of immuno-chemistry system which quantitatively measure multiple parameters.

With the SimplexTAS™101 you can perform single tests in a simple and easy way.

It is a compact and portable point-of-care system that can use a drop of blood from the fingertip, or urine samples.

Test is automated and can simultaneously run 4 different samples in 13 minutes.

User interface is a large touch screen where you can personalize various settings.

Specification +

Specification -

Size:
265(W)×217(L)×262(H) mm/10.4(W)×8.5(1)×10.3(H) in

Weight:
3.4kg/7.5 lbs

Display:
TFT LCD 5 inch touch panel

Memory capacity:
2000 patient results/200 control results/100 IQC results

Power input:
100-240 VAC 50-60 Hz 0.75 A

Power output:
43 VDC 1.5 A

Output connector:
0.2x0.1 in /5.5x2.5 mm plug Positive(+) on inner pin

Communication interface:
USB 2.0

Operating temperature:
18~32°C (64~89°F)

Operating humidity:
10~70% non-condensing

Storage temperature:
4~40°C (39~104°F)

Storage humidiy:
10~70% non-condensing

SW update:
Via USB memory
